BiG SiX (240v)
GH¢50,374.80
Solid State Logic BiG SiX 18-input Desktop Analog Mixer and Interface
Product Details
Specifications
BiG SiX combines production tools from iconic SSL studio consoles with the latest in hybrid workflow. G-Series Bus Compressor with renowned ‘Auto’ release, E-Series EQ, glorious sounding mic pres with channel processing, and advanced monitoring and routing, all designed on a SuperAnalogueTM foundation and brought together with full USB integration. BiG SiX is the essential SSL studio.
BiG SiX is the natural evolution of the modern-day studio classic, SiX. Incorporating feedback from a wide range of artist, producers and engineers, BiG SiX increases its capacity in almost all areas with four SuperAnalogueTM mic pres, four SuperAnalogueTM stereo inputs with dual mono switching, 3 band E-Series EQ on every channel, dual independent headphone outs with source matrix and much more.
Specifications
- Processor TypeAnalog Mixer with USB Interface
- Channels18 Inputs (includes summing and inserts), 8 Fader Channels
- Computer ConnectivityUSB (16 x 16)
- A/D Resolution24-bit/96kHz
- Faders9 x 100mm Faders
- Inputs - Mic Preamps4 x XLR
- Phantom PowerYes (per channel)
- Inputs - Line8 x 1/4" (4 x stereo channel), 4 x 1/4" (2 x external stereo input)
- Inputs - Other4 x 1/4" (Hi-Z)
- Outputs - Main2 x 1/4" TRS (main), 2 x 1/4" TRS (main monitor), 2 x 1/4" TRS (alt monitor)
- Aux Sends2 x Stereo Cue Send (pre/post)
- Busses/Groups2 x 1/4" TRS (Bus B out)
- Inserts2 x 1/4" TRS (L/R main bus insert send), 2 x 1/4" TRS (L/R main bus insert return)
- Headphones2 x 1/4"
- USB1 x USB-C
- Talkback1 x XLR
- EQ Bands:3-band EQ, High/Low Bell Curve, Mid Frequency Shift
- Signal ProcessingG-Series Bus Compressor (main mix bus), Channel Compression
- OS Requirements - MacOS X 10.14 or later
- OS Requirements - PCWindows 10 or later (SSL USB ASIO/WDM driver required)
- RackmountableOptional rackmount kit (sold separately)
- Power Source4-pin 15V DC power supply (included)
- Height5.6"
- Width:19.3" (including trim)
- Depth15.4"
- Weight15.0 lbs.
- Manufacturer Part Number729752X2
